Redonit 85
85 mm Class A premium series
85 mm Class A profile with 7 chambers, Uw 0.93 W/m²K and up to 44 dB sound insulation. 21 laminated colours.
Specifications
Redonit 85
- Profile width
- 85mm
- Chambers
- 7
- Gaskets
- 3
- Uw (window)
- 0.93W/m²K
- Uf (frame)
- 1.07W/m²K
- Sound insulation
- 44dB
- Glazing
- 20–44 mm
- Profile class
- A
- Air permeability
- Class 4
- Watertightness
- 9A
- Wind resistance
- C3
Values are based on manufacturer data and may vary with project conditions.
Passed a 3,000 Pa wind test (about 245 km/h) and a 600 Pa water test (about 110 km/h, 4 L/min). Compatible with 13 mm axis hardware.
Thermal values calculated to TS EN ISO 10077-2 for a 1.23 × 1.43 m window (Ug 0.6 W/m²K).
Opening types
- Side-hung and tilt-and-turn
- Parallel sliding
- Folding
- Pivot
- Security hardware
Colour options
- Golden Oak
- Antique Oak
- Acorn Oak
- Hazelnut
- Mahogany
- Winchester
- Mink
- Cream
- Silver
- Metallic Silver
- Anthracite Grey
- Metallic Anthracite
- Ash Black
